Learning-Based 3D Reconstruction of Power Networks from Aerial Point Clouds

Version one. Our first end-to-end pipeline at AiDash: aerial LiDAR in, poles, wires and connectivity out, per span. Everything since, BMVC and now ICLR, grew out of the gaps we found here.

Abstract

This paper presents an end-to-end framework for reconstructing overhead power utility network topology and extracting span-level physical metadata from large-scale aerial LiDAR. The pipeline begins with semantic segmentation of the input point cloud using an improved KPConv-based model, in which data sampling and loss functions are adapted to emphasize pole and conductor (wire) classes. Network topology inference then proceeds in two stages: (i) pole instances are obtained by clustering pole-class points and validating candidates using geometric criteria, including height and verticality estimated via PCA, and (ii) candidate pole pairs are evaluated using a heuristic method and a lightweight ResNet-based classifier on 2D top-view projections of pole and wire point distributions to determine whether a physical conductor span exists. By explicitly classifying candidate spans, the approach mitigates common failure modes of heuristic connectivity rules in dense or cluttered scenes and under partial wire observation. For each validated wire, attributes regarding utility infrastructure geometry are computed, including endpoint conductor heights, ground elevation, sag-related lowest-point features, conductor arrangement, and wire width. Evaluation on multiple real-world aerial LiDAR datasets demonstrates decimeter-level endpoint height accuracy and approximately 9% relative improvement of recall in topology reconstruction performance compared to heuristic nearest-neighbor baselines, with larger gains in complex layouts.
